Af49-155 3-Bar Map Sensor With 5Mm Vacuum Barb Port

Description

3 Bar Manifold Absolute Pressure (MAP) Sensorwith 5mm Vacuum Barb Port

AF49-1552

49-1552

The Aeroflow Performance Manifold Absolute Pressure (MAP) sensor is a 3 bar MAP sensor. This sensor is used to determine engine load on forced induction engines. This sensor is intended to be used on engines producing positive manifold pressure up to 2 bar, or roughly 30psi of boost. This sensor is not recommended for use with engines that will not see boost above 1 bar, as it limits sensor resolution. This sensor is fully calibrated for high accuracy and designed for high stability across the temperature range. It includes the plug and pins to easily wire into any application.This sensor has a 5mm vacuum barbOverall length is 52mmOverall width is 27.50mmOverall body height is 11.60mmOperating pressure range is 20 kpa to 400kpaSupply voltage range is 4.65 to 5.35 volts (working voltage is 5 volts)Response working time is 1 millisecond
