Wilwood 170-14206 Hd Fixed-Mount Rotor Hat For Big Brake Conversions

Description

Brand: Wilwood Disc Brakes
Manufacturer’s Part Number: 170-14206
Part Type: Brake Rotor Hats
Product Line: Wilwood HD Fixed Mount Brake Rotor Hats
Automotive Fittings Part Number: WIL-170-14206
UPC: 889545077339
Brake Rotor Hat Type: 5/16-18 in. threaded hole
Brake Rotor Hat Material: Aluminum
Brake Rotor Hat Color: Black
Brake Rotor Hat Bolt Circle: 8 x 7.00 in.
Brake Rotor Hat Offset (in.): 1.53
Brake Rotor Hat Stud Hole Diameter (in.): 0.52
Brake Rotor Hat Center Hole I.D. (in.): 3.06
Brake Rotor Hat Face Thickness (in.): 0.25
Quantity: Sold individually.
Notes: This Drag, shallow offset hat features a 1.530 in. offset, 6.22 in. clearance inside diameter, dual bolt circles (see the Applications section), and a counterbored center hole.
Description:
These Wilwood HD fixed mount brake rotor hats are manufactured from a premium-grade aluminum alloy offering high strength, low weight, and show-quality appeal. They feature straight bell construction with a flanged rotor mount ring. These rotor hats provide maximum radial clearance between the caliper body and the hats. They require the use of the correct Wilwood rotor bolt pattern for installation.
